Brushless motor 12VDC 1.9A 5400rpm 20W
Product name: BT3657-12 | SKU: 15999171
Brushless DC motor, BLDC motor voltage 12VDC current 1.9A speed 5400rpm power 20W. The motors include a range of supply voltages between 12-48V and have hall elements intended for connection to external drive electronics. Mechanical structures with circular or square flange. All motors can be customized per request. Common customizations are shaft dimensions, cable connections and cabling. Read more here about customizations and please contact us for further information.
≥ 1 pcs
€102.00
≥ 5 pcs
€82.00
≥ 25 pcs
€69.00
≥ 50 pcs
€59.50
≥ 100 pcs

Available on backorder

Power
20W
Voltage
12VDC
Nominal speed
5400rpm
Nominal torque
30mNm
Length
57mm
Nominal current
1.9A
Diameter
36mm
Weight
230g
SKU
15999171
Some of the possible customizations:
For any inquiries regarding customizations, please contact us at:
