Brushless motor 12VDC 1.8A 5200rpm 15W
Product name: BT3649-12 | SKU: 15999167
Brushless DC motor, BLDC motor voltage 12VDC current 1.8A speed 5200rpm power 15W. The motors include a range of supply voltages between 12-48V and have hall elements intended for connection to external drive electronics. Mechanical structures with circular or square flange. All motors can be customized per request. Common customizations are shaft dimensions, cable connections and cabling. Read more here about customizations and please contact us for further information.
≥ 1 pcs
€92.00
≥ 5 pcs
€74.00
≥ 25 pcs
€62.00
≥ 50 pcs
€53.50
≥ 100 pcs

Available on backorder

Power
15W
Voltage
12VDC
Nominal speed
5200rpm
Nominal torque
29mNm
Length
49mm
Nominal current
1.8A
Diameter
36mm
Weight
200g
SKU
15999167
Some of the possible customizations:
For any inquiries regarding customizations, please contact us at:
