Home / DC-motors  / Worm gear dc motors
Power
Voltage
Nominal speed
Nominal speed range
Nominal torque
Nominal torque range
Profile
Length
Nominal current
Diameter
Encoder

Worm gear DC-motors, direct current motors

Brush-commutated worm gear DC motors, direct current motors, with a power up to 400W. The motors include a range with supply voltages between 12-24V and can, depending on the type, be supplied with or without gear, encoder and brake. All motors can be customized per request. Common customizations are shaft dimensions, cable connections and cabling. Read more here about customizations and please contact us for further information.

DC-motors

Planetary gear

Spur gear

Worm gear dc motors


12345678
 186 items in 8 pages
WHD123224-12-10
Worm gear motor 12VDC 43A 202rpm 421W
Product name: WHD123224-12-10 | SKU: 141188009
Voltage
12VDC
Nominal speed
202rpm
Nominal torque
9.5883lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD123224-12-15
Worm gear motor 12VDC 43A 135rpm 421W
Product name: WHD123224-12-15 | SKU: 141188010
Voltage
12VDC
Nominal speed
135rpm
Nominal torque
11.801lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD123224-12-20
Worm gear motor 12VDC 43A 101rpm 421W
Product name: WHD123224-12-20 | SKU: 141188011
Voltage
12VDC
Nominal speed
101rpm
Nominal torque
15.4888lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD123224-12-30
Worm gear motor 12VDC 43A 67rpm 421W
Product name: WHD123224-12-30 | SKU: 141188012
Voltage
12VDC
Nominal speed
67rpm
Nominal torque
23.6019lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD123224-12-40
Worm gear motor 12VDC 43A 50rpm 421W
Product name: WHD123224-12-40 | SKU: 141188013
Voltage
12VDC
Nominal speed
50rpm
Nominal torque
30.24lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD123224-24-10
Worm gear motor 24VDC 22A 202rpm 421W
Product name: WHD123224-24-10 | SKU: 141188017
Voltage
24VDC
Nominal speed
202rpm
Nominal torque
9.5883lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

In stock

WHD123224-24-15
Worm gear motor 24VDC 22A 135rpm 421W
Product name: WHD123224-24-15 | SKU: 141188018
Voltage
24VDC
Nominal speed
135rpm
Nominal torque
11.801lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD123224-24-20
Worm gear motor 24VDC 22A 101rpm 421W
Product name: WHD123224-24-20 | SKU: 141188019
Voltage
24VDC
Nominal speed
101rpm
Nominal torque
15.4888lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

In stock

WHD123224-24-30
Worm gear motor 24VDC 22A 67rpm 421W
Product name: WHD123224-24-30 | SKU: 141188020
Voltage
24VDC
Nominal speed
67rpm
Nominal torque
23.6019lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD123224-24-40
Worm gear motor 24VDC 22A 50rpm 421W
Product name: WHD123224-24-40 | SKU: 141188021
Voltage
24VDC
Nominal speed
50rpm
Nominal torque
30.24lb-ft
Diameter
4.86in
1+
$1938.00
2+
$1718.50
5+
$1549.00
10+
$983.50
25+
Mail Mail
Spin UpSpin Down

In stock

WHD80141-12-10
Worm gear motor 12VDC 9,6A 245rpm 90W
Product name: WHD80141-12-10 | SKU: 147152071
Voltage
12VDC
Nominal speed
245rpm
Nominal torque
1.8439lb-ft
Diameter
3.15in
1+
$585.00
2+
$521.00
5+
$471.00
10+
$321.50
25+
Mail Mail
Spin UpSpin Down

In stock

WHD80141-12-10-B
Worm gear motor 12VDC 9,6A 245rpm 90W
Product name: WHD80141-12-10-B | SKU: 147152371
Voltage
12VDC
Nominal speed
245rpm
Nominal torque
1.8439lb-ft
Diameter
3.15in
1+
$812.00
2+
$721.00
5+
$647.00
10+
$441.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-10-ME
Worm gear motor 12VDC 9,6A 245rpm 90W
Product name: WHD80141-12-10-ME | SKU: 147152271
Voltage
12VDC
Nominal speed
245rpm
Nominal torque
1.8439lb-ft
Diameter
3.15in
1+
$735.00
2+
$652.00
5+
$587.50
10+
$400.00
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-10-OE
Worm gear motor 12VDC 9,6A 245rpm 90W
Product name: WHD80141-12-10-OE | SKU: 147152171
Voltage
12VDC
Nominal speed
245rpm
Nominal torque
1.8439lb-ft
Diameter
3.15in
1+
$814.50
2+
$723.00
5+
$650.00
10+
$442.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-15
Worm gear motor 12VDC 9,6A 163rpm 90W
Product name: WHD80141-12-15 | SKU: 147152072
Voltage
12VDC
Nominal speed
163rpm
Nominal torque
2.4339lb-ft
Diameter
3.15in
1+
$585.00
2+
$521.00
5+
$471.00
10+
$321.50
25+
Mail Mail
Spin UpSpin Down

In stock

WHD80141-12-15-B
Worm gear motor 12VDC 9,6A 163rpm 90W
Product name: WHD80141-12-15-B | SKU: 147152372
Voltage
12VDC
Nominal speed
163rpm
Nominal torque
2.4339lb-ft
Diameter
3.15in
1+
$812.00
2+
$721.00
5+
$647.00
10+
$441.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-15-ME
Worm gear motor 12VDC 9,6A 163rpm 90W
Product name: WHD80141-12-15-ME | SKU: 147152272
Voltage
12VDC
Nominal speed
163rpm
Nominal torque
2.4339lb-ft
Diameter
3.15in
1+
$735.00
2+
$652.00
5+
$587.50
10+
$400.00
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-15-OE
Worm gear motor 12VDC 9,6A 163rpm 90W
Product name: WHD80141-12-15-OE | SKU: 147152172
Voltage
12VDC
Nominal speed
163rpm
Nominal torque
2.4339lb-ft
Diameter
3.15in
1+
$814.50
2+
$723.00
5+
$650.00
10+
$442.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-20
Worm gear motor 12VDC 9,6A 122rpm 90W
Product name: WHD80141-12-20 | SKU: 147152073
Voltage
12VDC
Nominal speed
122rpm
Nominal torque
3.0978lb-ft
Diameter
3.15in
1+
$585.00
2+
$521.00
5+
$471.00
10+
$321.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-20-B
Worm gear motor 12VDC 9,6A 122rpm 90W
Product name: WHD80141-12-20-B | SKU: 147152373
Voltage
12VDC
Nominal speed
122rpm
Nominal torque
3.0978lb-ft
Diameter
3.15in
1+
$812.00
2+
$721.00
5+
$647.00
10+
$441.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-20-ME
Worm gear motor 12VDC 9,6A 122rpm 90W
Product name: WHD80141-12-20-ME | SKU: 147152273
Voltage
12VDC
Nominal speed
122rpm
Nominal torque
3.0978lb-ft
Diameter
3.15in
1+
$735.00
2+
$652.00
5+
$587.50
10+
$400.00
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-20-OE
Worm gear motor 12VDC 9,6A 122rpm 90W
Product name: WHD80141-12-20-OE | SKU: 147152173
Voltage
12VDC
Nominal speed
122rpm
Nominal torque
3.0978lb-ft
Diameter
3.15in
1+
$814.50
2+
$723.00
5+
$650.00
10+
$442.50
25+
Mail Mail
Spin UpSpin Down

In stock

WHD80141-12-25
Worm gear motor 12VDC 9,6A 98rpm 90W
Product name: WHD80141-12-25 | SKU: 147152074
Voltage
12VDC
Nominal speed
98rpm
Nominal torque
3.8353lb-ft
Diameter
3.15in
1+
$585.00
2+
$521.00
5+
$471.00
10+
$321.50
25+
Mail Mail
Spin UpSpin Down

In stock

WHD80141-12-25-B
Worm gear motor 12VDC 9,6A 98rpm 90W
Product name: WHD80141-12-25-B | SKU: 147152374
Voltage
12VDC
Nominal speed
98rpm
Nominal torque
3.8353lb-ft
Diameter
3.15in
1+
$812.00
2+
$721.00
5+
$647.00
10+
$441.50
25+
Mail Mail
Spin UpSpin Down

Available on backorder
WHD80141-12-25-ME
Worm gear motor 12VDC 9,6A 98rpm 90W
Product name: WHD80141-12-25-ME | SKU: 147152274
Voltage
12VDC
Nominal speed
98rpm
Nominal torque
3.8353lb-ft
Diameter
3.15in
1+
$735.00
2+
$652.00
5+
$587.50
10+
$400.00
25+
Mail Mail
Spin UpSpin Down

Available on backorder
