AIS-025W-120-SC
Speed adjustable AC-gear motors 110-120VAC, current 0.45-0.5A, rated speed at 90-1200rpm and power 25W.
Product name: AIS-025W-120-SC | SKU: 22300004
Induction AC-gear motors, alternating current motors voltage of 110-120VAC, current 0.45-0.5A, rated speed 90-1200rpmpower 25W. Transmotec sell a broad range of geared AC motors in standard and customized configurations. These speed adjustable AC motors are designed for applications that require the motor speed to be set at various speeds. The motors have a small analogue generator built to the rear shaft that is connected to a separate speed controller unit.Transmotec is the ideal supplier source specially to instrument and apparatus builders. We keep a high number of motors in stock for immediate delivery. All motors can be customized per request. Common customizations are shaft dimensions, cable connections and cabling. Read more here about customizations and please contact us for further information.
≥ 1 pcs
$111.57
≥ 5 pcs
$93.27
≥ 25 pcs
$81.07
≥ 50 pcs
$78.02
≥ 100 pcs

Available on backorder

Power
25W
Voltage
110-120VAC
Frequency
60Hz
Phases
1
Nominal speed
90-1200rpm
Nominal torque
50-190mNm
Nominal current
0.45-0.5A
Size
80x80mm
Type
Speed adjustable
Weight
1.7kg
SKU
22300004
Profile
Square
Some of the possible customizations:
For any inquiries regarding customizations, please contact us at:
Datasheet
Drawing
Catalog
3D CAD (.stp)
